Page 123 - GETELEC catalogue US 2020
P. 123

Rectangular profile cellular foam with


                 conductive metallised fabric coating,


                                 height : 3mm – 7.5mm



                                                                                                                   4
                                                     Manufacturing options :
                                                     - Length : 1 meter standard. Contact us for custom lengths
                                                     -  Filled : Cu/Ni as standard, silver or aluminum strip options
                                                       available.
                                                     - Available with conductive or non-conductive adhesive
                                                     - Contact us for non-listed sizes





                      Reference              Width mm (A)           Height mm (B)      Width of adhesive mm (C)
             RT 3 x 3 GT60000                    3.0                    3.0                    1.5
             RT 4 x 3 GT60000                    4.0                    3.0                    2.0
             RT 4.8 x 3.3 GT60000                4.8                    3.3                    2.0
             RT 5 x 3 GT60000                    5.0                    3.0                    2.0
             RT 5 x 4 GT60000                    5.0                    4.0                    2.0
             RT 5 x 5 GT60000                    5.0                    5.0                    2.0
             RT 6 x 3 GT60000                    6.0                    3.0                    2.5
             RT 6 x 4 GT60000                    6.0                    4.0                    2.5
             RT 6 x 5 GT60000                    6.0                    5.0                    2.5
             RT 6  x 6 GT60000                   6.0                    6.0                    2.5
             RT 6 x 7 GT60000                    6.0                    7.0                    2.5
             RT 6.4 x 3.2 GT60000                6.4                    3.2                    2.5
             RT 6.4 x 6.4 GT60000                6.4                    6.4                    2.5
             RT 7 x 3.2 GT60000                  7.0                    3.2                    3.0
             RT 7 x 4 GT60000                    7.0                    4.0                    3.0
             RT 8 x 3 GT60000                    8.0                    3.0                    3.0
             RT 8 x 4 GT60000                    8.0                    4.0                    3.0
             RT 8 x 5 GT60000                    8.0                    5.0                    3.0
             RT 9 x 3 GT60000                    9.0                    3.0                    4.0
             RT 9 x 6 GT60000                    9.0                    6.0                    4.0
             RT 9 x 7 GT60000                    9.0                    7.0                    4.0
             RT 9.5 x 3.2 GT60000                9.5                    3.2                    4.0
             RT 9.5 x 6.4 GT60000                9.5                    6.4                    4.0
             RT 10 x 3 GT60000                  10.0                    3.0                    4.0
             RT 10 x 4 GT60000                  10.0                    4.0                    4.0
             RT 10 x 5 GT60000                  10.0                    5.0                    4.0
             RT 10 x 5.5 GT60000                10.0                    5.5                    4.0
             RT 10 x 7 GT60000                  10.0                    7.0                    4.0
             RT 12.7 x 3.2 GT60000              12.7                    3.2                    5.0
             RT 12.7 x 6.4 GT60000              12.7                    6.4                    5.0
             RT 13 x 6 GT60000                  13.0                    6.0                    5.0
             RT 13 x 7 GT60000                  13.0                    7.0                    5.0
             RT 15 x 4 GT60000                  15.0                    4.0                    6.0
             RT 15 x 7.5 GT60000                15.0                    7.5                    6.0
             RT 21 x 4 GT60000                  21.0                    4.0                    8.0




                               UL94 V0
