Page 40 - GETELEC catalogue US 2020
P. 40
SILVER-PLATED ALUMINUM FILLED
CONDUCTIVE EPDM - GT 5200
GT 5200 is a conductive silver-plated aluminum filled EPDM elastomer
which enables the creation of sealed, conductive gaskets.
• Gas permeable
• Good abrasion resistance
• Good high temperature resistance
• Excellent mechanical performance
• Resistant to methyl, ethyl, ketone type
aggressive solvents.
Properties Standards - Test GT 5200
Type MIL G 83528 -
Elastomer binder EPDM
Silver-plated
Conductive filler
aluminum
Volume Resistivity Ω.cm MIL G 83528 < 0.015
Hardness shore A ASTM D 2240 70
Density ASTM D 792 Method A 2.00
Break resistance Mpa ASTM D 412 Method A C 1.70
Elongation at break % ASTM D 412 Method A C 470
Tear resistance N/mm ASTM D 624 C 12.00 AVAILABLE FORMATS
Residual deformation after 70 ASTM D 395 Method B 40 Molded
hours of compression at 100°C
Cut
Continuous usage -45°C to
temperature +160°C Sheet
Color Grey Vulcanization bonding
