SILVER-PLATED ALUMINUM FILLED

CONDUCTIVE SILICONE - GT 5000

GT 5000 is a conductive silver-plated aluminum filled conductive silicone
elastomer which enables the creation of sealed, conductive gaskets.
This is a conductive mixture which is compliant with the
MIL G 83528 Type B standard.

• Low density
• Excellent high-frequency performance
• Compatible with most alloys
• Very stable at high temperatures (peak 200°C)

Properties Standards - Test GT 5000 Specification
MIL G 83528
Type MIL G 83528 B -
Elastomer binder Silicone -
Silver-plated
Conductive filler -
aluminum
0.008
Volume Resistivity Ω.cm MIL G 83528 < 0.0054
maximum
Hardness shore A ASTM D 2240 65 65 ± 7
Density ASTM D 792 Method A 1.90 2.00
1.38
Break resistance Mpa ASTM D 412 Method A C 1.89
minimum
Elongation at break % ASTM D 412 Method A C 286 100-300
5.25
Tear resistance N/mm ASTM D 624 C 8.43
minimum AVAILABLE FORMATS
Residual deformation after 32
70 hours of compression ASTM D 395 Method B 17.30 maximum Molded
at 100°C
Cut
Continuous usage -55°C to -55°C to
temperature +160°C +160°C Extruded
Color Grey / Beige - Sheet
Vulcanization bonding
