Moulded waveguide

flange seals

Size of Flange type Getelec MIL 83528 Getelec 1
Frenquency Band wave- JAN article refe- 013 [ ]-( ) tool
range (GHz) guide désignation UG CPR CMR rence reference reference
26.50 - Ka WR28 RG-96/U UG-600A/U - - PF3457 [K]-(002) LR 121
40.00 (silver)
18.00 – K WR42 RG-53/U UG-596A/U - - PF8572 [ K ]-(004) LR 120
26.50 (brass) UG-598A/U

12.40 – RG-91/U UG-541A/U - - PF030040098 [ K ]-(006) LR 42
18.00 Ku WR62 (brass) - - - PF8573 - LR 41
10.00 – - WR75 - - - - PF030040100 [ K ]-(008) LR 35
15.00
UG-136A/U - - PF030040097 [ K ]-(011) LR 62
UG-40A/U
RG-52/U UG-136B/U
8.20 – 12.40 X WR90 (brass) UG-40B/U - - PF030040096 [ K ]-(012) LR 61
UG-1360/U
UG-1361/U CPR-90G - PF8574 [ K ]-(013) LR 116
UG-52B/U - - PF030040072 [ K ]-(017) LR 63
7.05 – 10.00 X1 WR112 RG-51/U UG-137B/U
(brass) UG-1358/U
UG-1359/U CPR-112G - PF040040013 [ K ]-(018) LR 117
RG-50/U UG-1356/U
5.85 – 8.20 Xb WR137 (brass) UG-1357/U CPR-137G - PF040040026 [ K ]-(023) LR 118
UG-148C/U - - PF030040016 [ K ]-(029) LR 65
3.95 – 5.85 C WR187 RG-49/U UG-406B/U
(brass) UG-1352/U
UG-1353/U CPR-187G - PF040040016 [ K ]-(030) LR 119
UG-54B/U - - PF030040017 [ K ]-(036) LR 66
RG-48/U UG-585A/U
2.60 – 3.95 S WR284 (brass) UG-1348/U
UG-1349/U CPR-284G - PF040040010 [ K ]-(037) LR 51

Material : Conductive silicone filled silver plated copper : Ref. GT 1000 (cf. chapter 1)

Shielding efficacy
Efficacité de blindage
160
140
120
Atténuation dB dB attenuation 80
100

60
40
20
0
20 MHz 100 MHz 500 MHz 2 GHz 10 GHz 18 GHz

GT1000
Norme MIL G 83528
GT 1006 Standard MIL G 83528
GT 1006
