Conductive silicone extruded
bi-material
Most of GT conductive materials can be extruded in various sections and profile shapes. The
vulcanization of the extruded seal ends allow the production of customized o-ring gaskets, without
tooling charge.
Large range of standard profiles available (see following pages).
For specific profiles, please contact us.
CHARACTERISTICS
CORROSION-RESISTANT CONDUCTIVE SILICONE ELASTOMER
MATERIAL SEALING ELASTOMER CONDUCTIVE FILLER MAX RESISTIVITY (mΩ/cm) MIL G 83528
GT 1040 Silicone 40 sh Silver-plated copper 15
GT 1060 Silicone 60 sh Silver-plated copper 15
GT 2040 Silicone 40 sh Silver 10
GT 2060 Silicone 60 sh Silver 10
GT 3140 Silicone 40 sh Nickel Graphite 100
GT 3160 Silicone 60 sh Nickel Graphite 100
GT 5040 Silicone 40 sh Silver-plated aluminum 8
GT 5060 Silicone 60 sh Silver-plated aluminum 8
GT 5068 EPDM-Si 65 sh Silver-plated aluminum 8
BL 10060 Silicone 60 sh Carbon < 6 Ω-cm
CORROSION-RESISTANT CONDUCTIVE FLUOROSILICONE ELASTOMER
MATERIAL SEALING ELASTOMER CONDUCTIVE FILLER MAX RESISTIVITY (mΩ/cm) MIL G 83528
GT 1047 Fluorosilicone 40 sh Silver-plated copper 15
GT 1067 Fluorosilicone 60 sh Silver-plated copper 15
GT 2047 Fluorosilicone 40 sh Silver 10
GT 2067 Fluorosilicone 60 sh Silver 10
GT 3147 Fluorosilicone 40 sh Nickel Graphite 100
GT 3167 Fluorosilicone 60 sh Nickel Graphite 100
GT 5047 Fluorosilicone 40 sh Silver-plated aluminum 8
GT 5067 Fluorosilicone 60 sh Silver-plated aluminum 8
BL 10067 Fluorosilicone 60 sh Carbon < 6 Ω-cm
RADIUS OF CURVATURE
Solid round section The minimum inner radius of curvature is 1.5 times the cross section of the profile
The minimum inner radius if curvature is 2.5 times the cross section of the profile insofar as
Hollow round section (tube)
the inner diameter of the tube does not exceed 30% of its section.
