SILVER PLATED COPPER FILLED

FLUOROSILICONE - GT 1007

GT 1000 is a conductive silver-plated copper filled silicone elastomer, GT 1007 is a silver plated copper filled fluorosilicone conductive silicone
which enables the creation of sealed conductive gaskets. This is a elastomer which enables the creation of sealed, conductive gaskets,
conductive mixture which is compliant with the MIL G 83528 which can come into contact with solvents, oils, hydrocarbons or
type K Standard. hydraulic fluids. This is a conductive mixture which is compliant
with the MIL G 83528 Type C standard.

• Good EMP resistance
• Low degassing rate
• Both electrically and thermally conductive
• Excellent stability over time

Thanks to his low degassing rate, the GT 1007 is suitable for aerospace applications.

Properties Standards-test GT 1007 Specification
MIL G 83528
Type MIL G 83528 Type C
Elastomer binder Fluorosilicone
Silver-plated
Conductive filler MIL G 83528
copper
Volume Resistivity Ω.cm ASTM D 2240 < 0.006 0.010
Hardness shore A ASTM D 792 Method A 73 75 ±7
Density ASTM D 412 Method A C 3.90 4.00 ± 13%
1.24
Break resistance Mpa ASTM D 412 Method A C 1.79
minimum
Elongation at break % ASTM D 412 Method A C 250 100-300
6.13 AVAILABLE FORMATS
Tear resistance N/mm ASTM D 624 C 8.92
minimum
Residual deformation after 35 Molded
70 hours of compression at ASTM D 395 Method B 25.30 maximum
100°C Cut
Continuous usage -55°C to +125°C -55°C° to Extruded
temperature +125°C
Vulcanization bonding
Color Grey / Beige
Sheet
