P. 138
Thermally conductive electrical
insulators (Standard die-cut)
Ref. A (mm) B (mm) C (mm) D (mm)
A
D 51 40.50 28.00 4.00 1.80
TO-3
C 463 43.00 30.00 3.50 2.00
B H 21 43.20 30.00 4.00 1.60
D 53 44.00 31.80 3.60 1.60
E 72 48.10 34.70 2.90 1.30
C (ø) D (ø) C 4 49.40 36.50 3.60 1.60
S 15 52.00 35.00 5.50 4.50
TO-66
Ref. A (mm) B (mm) C (mm) D (mm) A
F 66 31.80 17.80 3.50 1.60
C 461 34.00 20.00 3.50 1.20
B
F 67 34.90 21.00 3.60 1.60
D 45 36.80 22.80 3.60 1.20
C (ø)
D (ø)
D (ø)
TO-36 A
Ref. A (mm) B (mm) C (mm) D (mm)
B E 26 22.00 16.50 8.30 3.60
c
B
