MS composite seals

MS composite seals are an EMI/RFI product made of an aluminum 7
wire mesh impregnated with 50 shore hardness silicone or neoprene
elastomer.

Use :
• Seals made with these materials ensure an electrical connection and
sealing, while maintaining good salt fog resistance.

• These materials are available as sheets or cut gaskets in diffrent
elastomers and thicknesses. (See table below)

Getelec reference Thickness Elastomers Aluminum mesh
MS 16 0.4 mm Neoprene 30
MS 20 0.5 mm Neoprene 24
MS 516 0.4 mm Silicone 30
MS 520 0.5 mm Silicone 24

ATTENUATION

Field H 100 KHz 40 – 50 dB
Field E 10 MHz 100 dB
Plane wave 1 GHz 50 – 60 dB

WORKING TEMPERATURE

Silicone elastomer -60°C to +250°C 40 – 50 dB
Neoprene elastomer -40°C to +100°C 100 dB
Formats
Contact us for standard shapes and pre-cut gasket.
